1. Cov lus qhia luv luv:
Phosphine Ph3 gas detector yog tsim rau ntau yam kev lag luam ib puag ncig thiab tshwj xeeb ib puag ncig kev ntsuas roj, cov ntsiab lus tseem ceeb yog: electrochemistry, infrared, catalytic combustion, thermal conductivity, PID photoion, siv microcontroller technology thiab kernel algorithm ua, tau txais ib tug xov tooj. ntawm software patents thiab patents. Cov lus teb ceev ceev, ntsuas qhov tseeb, kev ruaj ntseg zoo thiab rov ua dua, txhua yam tsis tuaj yeem ua raws, kev ua haujlwm yooj yim. Ua-nyob rau hauv 1800mA loj muaj peev xwm polymer rechargeable roj teeb; Siv cov kua siv lead ua kua tshuaj ntsuam xyuas, tso saib cov ntsuas kev qhia thiab cov nqi roj concentration, koj tuaj yeem saib cov ntaub ntawv keeb kwm ntawm lub vijtsam, nrog rau kev khaws cia, cov ntaub ntawv xa tawm thiab lwm yam haujlwm.
1) LCD zaub nrog lus Askiv zaub mov
2) Ntsuas ntau yam 0--1000ppm/0--20ppm
3) Adjustable tswb taw tes thiab xoom-set
4) Suab, pom, vibration tswb
5) USB interface them
6) tuaj yeem khaws 3000 lub tswb
7) Khoos phis tawj rau kev txheeb xyuas cov ntaub ntawv thiab luam tawm
2. Cov lus qhia ntxaws:
Xi'an Huafan thev naus laus zis portable phosphine ph3 gas detector yog ib hom kev tshawb nrhiav tsis tu ncua ntawm oxygen, tshuaj lom thiab teeb meem roj concentration ntsuas hauv qhov chaw ua haujlwm. Ntes rau ntuj diffusion nrhiav kom pom cov roj concentration, siv cov sensors txawv teb chaws, nrog zoo rhiab heev thiab zoo heev repeatability; Cov cuab yeej siv cov cuab yeej siv microcontrol, kev ua haujlwm yooj yim, ua tiav cov haujlwm, muaj kev ntseeg siab, nrog ntau yam kev hloov kho; tawg code kua siv lead ua zaub, intuitive ntshiab; Compact thiab zoo nkauj tsim tsis tsuas yog ua rau koj nyiam muab tso yooj yim dua rau koj tsiv mus siv.
Lub plhaub ntawm qhov ntsuas roj no & lub tswb nrov yog ua tau zoo ntawm PC, nrog lub zog siab, kub thiab corrosion kuj thiab zoo txhais tes. Siv dav hauv metallurgy, fais fab nroj tsuag, tshuaj lom neeg kev lag luam, mine, tunnel, qhov, underground pipeline thiab lwm qhov chaw, tuaj yeem tiv thaiv qhov tshwm sim ntawm kev sib tsoo.
3. Cov khoom parameter:
|
Lub npe |
Phosphine ph3 gas detector portable |
|
Sensor |
Electrochemical Sensor |
|
Ntsuas roj |
Phosphin ph 3 |
|
Ntsuas ntau yam |
{{0}}ppm/0-1000ppm 0.1ppm/1ppm |
|
Teb sijhawm |
Tsawg dua los yog sib npaug li 20s |
|
Cia |
Txuag 3000 cov ntaub ntawv ceeb toom thiab tus nqi ntawm lub sijhawm |
4. Ntsuas roj:
|
Tsis muaj |
Kev Ntsuas Gas |
Roj |
Ntsuas Ntau |
Kev daws teeb meem |
Tswb Point (Low/High) |
|
1 |
Combustible Gas |
EX |
0-100 feem pua LEL |
1% LE |
25/50 feem pua LEL |
|
2 |
Oxygen |
O2 |
0-30 feem pua VOL |
0.1% VOL |
18% / 23% VOL |
|
3 |
Hydrogen sulfide |
H2S |
0-200 ppm |
0.1 ppm |
10/20 ppm |
|
4 |
Cov pa roj carbon monoxide |
CO |
0-1000/2000 ppm |
1ppm ua |
50/150 ppm |
|
5 |
Nitrogen Dioxide |
TSIS MUAJ 2 |
0-20 ppm |
0.1 ppm |
5/10 ppm |
|
6 |
Nitric Oxide |
TSIS MUAJ |
0-250 ppm |
1ppm ua |
25/50 ppm |
|
7 |
Cov pa roj carbon dioxide |
CO2 |
0-5 feem pua VOL |
0.01 feem pua VOL |
0 2-0.5 VOL |
|
8 |
Sulfur Dioxide |
SO2 |
0-100 ppm |
0.1 / 1 ppm |
5/10 ppm |
|
9 |
Chlorine |
CL2 |
0-20 ppm |
0.1 ppm |
1/2 ppm |
|
10 |
Ammonia |
NH3 |
0-200 ppm |
1ppm ua |
35 / 70 ppm |
|
11 |
Hydrogen |
H2 |
0-1000 ppm |
1ppm ua |
35 / 70 ppm |
|
12 |
Phosphine |
PH 3 |
0-1000 ppm |
1ppm ua |
5/10 ppm |
|
13 |
Hydrogen Chloride |
HCL |
0-100 ppm |
1ppm ua |
10/20 ppm |
|
14 |
Ozone |
O3 |
0-50 ppm |
0.1 ppm |
5/10 ppm |
|
15 |
Hydrogen Floride |
HF |
0-50 ppm |
1ppm ua |
5/10 ppm |
|
16 |
Methanol |
CH4O |
0-100 ppm |
1ppm ua |
5/10 ppm |
|
17 |
Formaldehyde |
HCHO |
0-100 ppm |
1ppm ua |
10/20 ppm |
|
18 |
Ethylene Oxide |
ETO |
0-100 ppm |
1ppm ua |
10/20 ppm |
|
19 |
Nitrogen |
N2 |
70-100 VOL |
0.1 VOL |
82/90 VOL |
|
20 |
Organic Compound |
VOC |
0-100 ppm |
1ppm ua |
10/20 ppm |
5. Daim ntawv thov:
Phosphine yog cov pa roj uas tsis muaj xim, tsis tshua muaj tshuaj lom, tsw ntxhiab tsw. Phosphine gas muaj qhov cuam tshuam zoo rau cov kab sib txawv ntawm cov kab tsuag kab tsuag (tshwj tsis yog hmoov mites). Phosphine, raws li tus neeg sawv cev tswj hwm kab ntau, yog siv dav hauv fumigation thiab tshuaj tua kab ntawm nplej thiab pluab warehouses thiab cabins. Nyob rau hauv tus txheej txheem ntawm muab phosphine mus rau hauv kev siv, vim yog siv tsis zoo los yog to, qhov concentration tshaj tus qauv los yog ua rau phosphine lom. Yog li ntawd, nyob rau hauv granary, haus luam yeeb thiab lwm yam kev siv ntawm phosphine tshem tawm lub sij hawm yuav tsum tau siv phosphine ph3 gas detector, thaum qhov tshwm sim ntawm to los yog ntau ntau concentration yuav ceeb toom raws sij hawm, kom tsis txhob muaj tshwm sim ntawm lom tshwm sim.
xa ntawv:golf@huafankj.com
WhatsApp / Wechat: ntxiv rau 0086 15721910713
6. FAQ:
Q1: MOQ?
A: 1 pcs
Q2: Lub sijhawm xa khoom ntawm lub ntsuas roj.
A: 7 hnub tshwj xeeb tshwj xeeb cov pa roj.
Q3: Koj puas muaj kev tswj xyuas zoo.
A: Cov txheej txheem tswj xyuas nruj nruj los ntawm kev ntsuas sensor, PCB board vuam thiab kuaj, sib dhos lub tsev rau calibration.100 feem pua kev tshuaj xyuas.
Q4: Cov ntawv pov thawj twg koj tuaj yeem txhawb nqa?
A: Explosion-proof CNEX, ISO9001, CE thiab ATEX.
Q5: Koj lub khw muag khoom loj nyob qhov twg.
A; Hauv Asia thiab Europe.
Q6: Lub sijhawm khoom xa tuaj.
A: DAP los ntawm DHL, FEDEX lossis UPS. EXW los yog hiav txwv.
