1. Cov lus qhia luv luv:
Pump-suction nitrogen gas leak detector yog cov cuab yeej siv siab heev thiab meej siv hauv ntau qhov chaw los kuaj xyuas cov qib nitrogen hauv ib puag ncig. Cov cuab yeej muaj qhov ntsuas siab heev uas pom tau txawm tias qhov tsawg kawg nkaus ntawm nitrogen tam sim no hauv huab cua. Cov cuab yeej yog tsim los nrog cov cuab yeej siv thev naus laus zis, ua rau nws muaj zog, txhim khu kev qha, thiab meej.
2. Cov lus qhia ntxaws:
Cov qauv ntawm lub twj tso kua mis-suction nitrogen gas leak detector muaj lub tshuab nqus tsev twj, sensor, LCD zaub, khawm fais fab, thiab khawm calibration. Lub tshuab nqus tsev nqus nqus nqus nqus cov cua nyob ib puag ncig thiab hla nws los ntawm lub sensor, qhov twg nws tau txheeb xyuas cov ntsiab lus nitrogen. Cov ntaub ntawv txheeb xyuas tom qab ntawd tso tawm rau ntawm lub vijtsam LCD kom nyeem tau yooj yim. Lub khawm calibration enables tus neeg siv ua ib tug ceev calibration ntawm lub ntsuas kom paub tseeb tseeb.
Lub twj tso kua mis-suction hom nitrogen gas detector yog ua los ntawm rub cua los ntawm nws cov sensor. Cov huab cua yog kos rau hauv lub cuab yeej los ntawm lub twj tso kua mis thiab tau soj ntsuam los ntawm lub sensor rau muaj cov pa nitrogen. Cov cuab yeej tau nruab nrog lub tswb nrov thaum kuaj pom cov pa nitrogen, ceeb toom tus neeg siv kom ceev faj kom tsim nyog.
3. Technical parameters:
|
Khoom npe: |
Portable N2 Gas Detector nrog twj tso kua mis |
|
Qauv: |
HFP-1201(BX) |
|
Khoom loj: |
180 * 71 * 51mm |
|
Khoom hnyav: |
230g |
|
Ntes roj: |
N2 |
|
Txoj kev coj mus kuaj: |
Tso dej |
|
Ntsuas ntau: |
70-100%vol |
|
Kev daws teeb meem: |
0.1%vol |
|
Zaub: |
LCD zaub, hauv lus Askiv piav qhia |
|
Lub tswb hom: |
Suab, pom, vibration |
|
Fais fab mov: |
Rechargeable lithium roj teeb (1800mAh) |
|
Lub sijhawm them nyiaj: |
3-6 teev |
|
Lub sijhawm ua haujlwm: |
15 teev rau lel roj, roj toxic 7 hnub (tsuas yog lub tswb) |
|
Daim ntawv pov thawj: |
CE, ATEX |
|
Ua haujlwm kub: |
-20 degree -50 degree |
|
Ua haujlwm humidity: |
15% - 95%RH |
|
Yeem muaj nuj nqi: |
loading cov ntaub ntawv mus rau lub PC los xyuas cov ntaub ntawv nyob rau hauv lub sij hawm. |
4. Daim ntawv thov:
Hom nitrogen gas leak detector no feem ntau yog siv rau hauv qhov chaw kaw xws li tso tsheb hlau luam, qhov dej, thiab cov kav dej phwj tuaj uas muaj kev pheej hmoo ntawm cov roj nitrogen . Nws kuj tseem siv dav hauv kev lag luam xws li tshuaj lom neeg, tshuaj, roj thiab roj, thiab kev ua liaj ua teb, qhov twg cov roj nitrogen tuaj yeem tsim tawm thaum muaj ntau yam txheej txheem.
5. Calibration:
Cov Khoom Siv Yuav Tsum Tau: Pump-suction type nitrogen gas detector, nitrogen gas cylinder, flow meter, calibration adapter, and a calibration gas regulator.
Calibration txheej txheem:
Kauj Ruam 1: Qhib cov roj nitrogen lub tog raj kheej thiab teeb tsa tus nqi ntws mus rau qib qis tshaj plaws.
Kauj Ruam 2: Txuas lub ntsuas ntsuas mus rau lub tog raj roj nitrogen thiab teeb tsa tus nqi ntws mus rau qib uas xav tau.
Kauj ruam 3: Txuas lub calibration adapter mus rau lub gas detector thiab lub calibration gas regulator.
Kauj ruam 4: Qhib lub twj tso kua mis-suction hom nitrogen gas detector thiab tos kom nws sov.
Kauj ruam 5: Ntxig lub calibration gas regulator rau hauv lub calibration gas ntim thiab tig nws.
Kauj Ruam 6: Pib nqus cov roj calibration rau hauv lub tshuab ntes siv lub twj tso kua mis. Gas detector yuav cia li tso saib cov calibration concentration.
Kauj Ruam 7: Kho qhov calibration zaus mus rau qib uas xav tau thiab sau cov ntawv nyeem.
Kauj Ruam 8: Xyuas kom tseeb tias cov ntawv nyeem yog qhov tseeb thiab nyob rau hauv qhov kev lees paub.
Kauj Ruam 9: Yog tias qhov kev nyeem ntawv tsis nyob hauv qhov kev lees paub, rov ntsuas lub ntsuas thiab rov ua cov txheej txheem calibration.
